Equipment Introduction:
1. This equipment is a customized model mainly for semi-automatic assembly of automotive parts.
2. This device is a general-purpose device.
3. This equipment is semi- automatic assembly equipment . Large products are placed manually, the vibration plate automatically loads and rivets, with high speed, very stable, convenient and fast.
4. Equipped with a programmable controller (PLC), the mechanical actions are all designed by software and tested by computer to ensure that each action is reasonable and conflict-free. The equipment control interface is a full touch human-machine interface, which can be operated according to the prompts on the interface. It is simple and clear, and novices can also operate it skillfully. The equipment has automatic counting and automatic alarm functions, which is convenient for operators to calculate production and troubleshoot faults.
Application areas:
Semi-automatic assembly machines for auto parts are used in the automotive, hardware and electronic parts industries: auto parts, hardware accessories, electronic appliances, and other products that cannot be fully automatically loaded.
Technical Parameters:
Device Name | Semi-automatic assembly machine for auto parts |
model | YL-QC160803 |
power | 2.7KW |
Voltage | 380V/50Hz |
Air pressure | 0.4-0.7MPA |
Equipment capacity | 15-20PCS/MIN |
Features | Multiple universal |
Total weight of unit | 800kg |
Overall dimensions (length x width x height) | 1700×1700×1400mm |
