Equipment Introduction: Nut Testing Machine
1. This equipment is a standard model, mainly used for the go/no-go gauge detection of automotive nuts, electronic nuts, or other fastening nuts, effectively reducing labor and increasing the detection speed.
2. This device is a general-purpose device.
3. This equipment is fully automated for testing, with automatic loading on the vibration plate and automatic loading, testing and unloading by the robot. The operator only needs to pour the processed products into the vibration plate. It is convenient and fast, and one person can operate multiple devices at the same time.
4. Equipped with a programmable controller (PLC), the mechanical actions are all designed by software and tested by computer to ensure that each action is reasonable and conflict-free. The equipment control interface is a full touch human-machine interface, which can be operated according to the prompts on the interface. It is simple and clear, and novices can also operate it skillfully. The equipment has automatic counting and automatic alarm functions, which is convenient for operators to calculate production and troubleshoot faults.
Application areas:
Nut go/no-go gauge screening machine is used in the automotive and electronics industries: automotive fastening nuts, automotive welding nuts, electronic copper nuts, electronic titanium nuts, or other fastening nuts, etc.
Technical Parameters:
product name | Nut pass/no-pass gauge screening and testing machine |
model | YL-QC161020 |
power | 2KW |
Voltage | 220V/50Hz |
Air pressure | 0.4-0.7MPA |
Equipment capacity | 35PCS/MIN |
Features | Multiple universal |
Total weight of unit | 800kg |
Overall dimensions (length x width x height) | 1600×800×1800mm |
