Environmental aging test chamber series

Internal dimensions W×H×D (cm)

60×50×70

117×45×50

115 x H40 x D40

External dimensions W×H×D(cm)

85×65×118

130×55×148

140 x H145 x 65

Irradiation lamp model

    UVA-340/UVB-313 optional

     UVA-340/UVB-313 optional

      UVA-340/UVB-313 optional

Irradiance

0.3~1.0W/m2

Adjustable within 1.0W/m2

Adjustable within 1.0W/m2

humidity

≥90%RH or above

≥90%RH or above

≥90%RH or above

Temperature control method

                       PID self-tuning SSR control

Controller

           Original imported Korean TEMI microcomputer color LCD display touch screen controller

UV wavelength

    UVA340 range is 315-400nm/UVB313 range is 280-315nm

Test time

                          0~999H programmable

Irradiation blackboard temperature

                           50℃~70℃ adjustable

Security protection

Ground protection, power overload short circuit breaker, control circuit overload, short circuit fuse, over temperature protection,

Usage Environment

1. Ambient temperature: 5℃~+32℃; 2. Ambient humidity: ≤85%;

Product Power

380/220V/50HZ 32A
